Product Details:
|
| Output Type: | NPN / PNP | Detection Mode: | Diffuse Reflection / Through Beam |
|---|---|---|---|
| Supply Voltage: | 12-24 VDC | Light Source: | 650nm Red Modulated Light |
| Operating Ambient Temperature: | -25°C To 55°C | IP Protection Grade: | IP66 |
| Item | Specification |
|---|---|
| Brand | LOUSHIDA |
| Model Series | GQD-CB11 (Diffuse Reflection Mode) / GQT-CB11, GQT-CB13 (Through Beam Mode) |
| Output Type | NPN / PNP |
| Detection Mode | Diffuse Reflection / Through Beam |
| Detection Distance | Diffuse reflection: 2~40mm
|
| Minimum Detectable Object | Φ1mm opaque object (less than 15% of operating distance) |
| Power Supply Voltage | 12-24 VDC |
| Light Source | 650nm red modulated light |
| Indicator Light | Power indicator: green light
|
| Maximum Output Current | 50mA |
| Consumption Current | Less than 25mA |
| Response Time | Less than 1ms (operation and repetition) |
| Protection Function | Reverse connection protection, short circuit protection |
| Operating Ambient Temperature | -25°C to 55°C |
| Ambient Humidity | 35% to 85% relative humidity |
| Ambient Light Resistance | Daylight: 10000lux, Incandescent light: 3000lux |
| IP Protection Grade | IP66 (IEC standard) |
| Housing Material | ABS engineering plastic |
| Vibration Resistance | 10~500Hz, double amplitude 3mm, X/Y/Z axis, test for 2 hours |
| Impact Resistance | 500m/s², X/Y/Z axis, test 3 times |
Founded in 2012, Luoshida is a high-tech enterprise dedicated to the R&D, production, sales and service of sensors. Its core products cover a wide range of types, including inductive/capacitive proximity sensors, laser displacement sensors, through-beam/diffuse-reflective photoelectric sensors, fiber optical sensors, and color mark sensors, which are widely applied in industrial automation, smart manufacturing and electronic equipment.
FAQ
Relevant information about the service :
Shipping ways :
Our normal shipping way is internation express, such as DHL,FEDEX, TNT and so on;
When the gross weight is over 45kg, air trnasportation is also a good way for the customers to save some cost;
Sea transportation is also can be considered, but only appointed agent accetpable.
Payment term and delivery time :
1. Generaly speaking, 30% deposit in advance, balance paid before the shipping;
2. Sometimes the paypal payment method is also ok if the total amount is less than 500USD, such as sample fee;
3. Delivery time:
The sensors will be shipped out in 3 days when we receive the payment if we have stocks;
If no stocks, the delivery time will be 7-10days when we received the PO or deposit.
After-sales services :
1. The warranty period is 12 months
2. If we send the wrong parts to you, free replacement will be available
3. As for the installation of the parts. if you have any questions, please do not hesitate to contact us at any time.
