Product Details:
|
| Brand: | LUOSHIDA | Output Type: | NPN / PNP, Normally Open / Normally Closed |
|---|---|---|---|
| Sensing Distance: | 20 Meters | Response Time: | 5 Ms |
| Housing Material: | Aluminum Alloy | Switching Delay: | Less Than 15% Of Rated Sensing Distance (Sr) |
| Spot Size: | Standard About 2 Mm | Ingress Protection: | IP65 Dustproof And Waterproof |
| Operating Voltage: | 10 Volts To 30 Volts Direct Current | Operating Temperature: | Operating Temperature |
| Response Time: | 5 Milliseconds | Maximum Load Current: | 150 Milliamps |
| Leakage Current: | Less Than 0.01 Milliamps |
Specification of the sensor :
| Product name | Through Beam Laser Sensor | |
| No-load current | Less than 10 mA | |
| Temperature drift | Less than 10% of rated sensing distance (Sr) | |
| Maximum load current | 150 mA | |
| Warranty | 12 Months | |
| Short-circuit protection | Built-in support | |
| Leakage current | Less than 0.01 mA | |
| Overload protection threshold | 180 mA | |
| Voltage drop | Less than 1.5 V | |
| Switching frequency | 100 Hz | |
| Certificate | CE RoHS |
|
Founded in 2012, Luoshida is a high-tech enterprise dedicated to the R&D, production, sales and service of sensors. Its core products cover a wide range of types, including inductive/capacitive proximity sensors, laser displacement sensors, through-beam/diffuse-reflective photoelectric sensors, fiber optical sensors, and color mark sensors, which are widely applied in industrial automation, smart manufacturing and electronic equipment.
FAQ
Relevant information about the service :
Shipping ways :
Our normal shipping way is internation express, such as DHL,FEDEX, TNT and so on;
When the gross weight is over 45kg, air trnasportation is also a good way for the customers to save some cost;
Sea transportation is also can be considered, but only appointed agent accetpable.
Payment term and delivery time :
1. Generaly speaking, 30% deposit in advance, balance paid before the shipping;
2. Sometimes the paypal payment method is also ok if the total amount is less than 500USD, such as sample fee;
3. Delivery time:
The sensors will be shipped out in 3 days when we receive the payment if we have stocks;
If no stocks, the delivery time will be 7-10days when we received the PO or deposit.
After-sales services :
1. The warranty period is 12 months
2. If we send the wrong parts to you, free replacement will be available
3. As for the installation of the parts. if you have any questions, please do not hesitate to contact us at any time.
